Further Enhanced Turning CapacityThe largest turning capacity in its class is achieved with 24" max. chuck size and 830 mm (32.7 inch) of max. turning diameter.
Highest Power and Machining Performance in its Class.The spindle motor provides 45 kW (60.3 Hp) and 2592 N.m (1912.9 ft lbs) of power and torque respectively, offering the best performance in its class. A variety of spindle specifications are available to suit customers’ diverse requirements.
Improved Operational Efficiency, Including Chip Disposal and Operation Panel.The bed structure has been redesigned to facilitate the efficient disposal of high volumes of chips. In addition, the height of the operation panel can be adjusted for optimum convenience. Fixed type pendants are also available to suit customers’ requirements.
Basic Structure The frame and structure are redesigned to accommodate the enhanced specifications. The rapid traverse is increased to 20 m/min (787.4 ipm) for higher productivity.
The integral box guideway bed design provides vibration-free performance and ensures heavy duty and high precision cutting over long term operation.
Wider Machining Area The turning center now offers larger turning diameter and swing of workpiece.
Wider machining area for larger / more diverse workpieces.
Stronger Spindle The highly rigid gearbox structure provides the highest power / torque in its class for heavy duty cutting and optimum performance. A variety of spindle specifications are available to suit customers’ diverse requirements.
Higher reliability and rigidity with improved base and and spindle motor assembly.
Fast and Accurate Turret The new servo motor turret increases indexing speed and accuracy. The M model uses BMT75P turret to provide excellent milling performance and reduced thermal error due to low heat generation design.
The new servo turret facilitates faster indexing and accurate positioning.
Capto tool of ATC provide the higher productivity at difficult to cut material
The improved chip disposal system offers improved maintainability for either manual operation or automated system.
The 8300 Series offers the scope to cut large diameter workpieces and complete milling, drilling and tapping operations in a single setup.
Various optional features are available to suit customers’ diverse applications.
FANUC CNC has been optimized for DOOSAN's machine tools to maximize productivity.
Productivity Improvement Non-cutting times have been reduced, such as faster turret indexing time, increased axis rapid speed and acc/dec rates, which improves production cycle times and optimizes productivity.
Power Saving Function The automatic power saving function minimizes power consumption and helps maintain a pleasant working environment.
